110V Wireless Remote Control for Dust Collector Starter Outlet Switch

• UL-certified US standard 3-pin AC power socket. UL-certified US standard 14AWG power cord. And the switch's shell is made of PA-765 flame retardant material. Make you safer and more reliable at work.
• The Remote Control is capable of controlling multiple units of Dust Collector Remote Switch at the same time. They are suitable for use with a variety of appliances such as vacuum, dust collector, power feed, work lamp, etc. The Remote Control signals can penetrate walls. If not blocked, the signals travel as far as 50 meters.
• Package Included: *Automatic Vacuum Switch with 6' Power Cord X 1; *Remote Controller X 1; *CR2032 Coin Battery X1 (The battery is included in the remote control); *Installation Instruction X 1
• Input Voltage 110 volts AC. Maximum 15 amps; maximum horsepower 2.4HP. The Remote Control Switch is soft start mode,when click the remote control's ON/OFF button, the dust collector will start automatically. And the dust collector reaches to its full speed in 3 seconds after being turned on.When the work is completed, click the remote control and the dust collector keeps running for 2-3 more seconds before it shuts down.

O'SKOOL 110V Wireless Remote Control for Dust Collector Starter Outlet Switch

Using the Dust Collector Remote Control Switch and Remote Control, you can control your dust collector from any place in the workshop. You are spared the hassle of walking over to manually operate the dust collector. You can start or shut down the dust collector easily by pressing the Remote Control’s ON/OFF button.

Soft Start Mode

• The Dust Collector Remote Control Switch is soft start mode,when click the remote control's ON/OFF button, the dust collector will start automatically. And the dust collector reaches to its full speed in 3 seconds after being turned on.
• When the work is completed, click the remote control and the dust collector keeps running for 2-3 more seconds before it shuts down.
• Soft start mode can avoid excessive instantaneous current, slow down the speed of voltage rise, and prolong the service life of electrical appliances.

Electrical Specifications Dust Collector Remote Control Switch

• Electrical specifications: 15A/120VAC/60Hz/1800W/2.4HP
• RF reception frequency: 433.92 MHz
• Maximum instantaneous current: 20 A
• Maximum instantaneous power: 2.4 HP

Remote Control

• Power source: CR2032 battery, 210mA/HR
• Standby current: 1 uA
• Operating current: 10-15 mA/SEC
• CR2032 button cell is used. The battery life is two years if the remote Control is unused. It is expected to last one year under normal usage.

Warning

• The total operating current of all electrical appliances used with the Switch must not exceed 15 A.
• The Remote Control is capable of controlling multiple units of Dust Collector Remote Control Switch. When there is more than one unit of Switch within the remote control distance range, please make sure whether all need to be turned on simultaneously.

• Input Voltage 110 volts AC.
• Maximum 15 amps; maximum horsepower 2.4HP.

Package Included

• Automatic Vacuum Switch with 6' Power Cord X 1
• Remote Controller X 1
• CR2032 Coin Battery X1 (The battery is included in the remote control)
• Installation Instruction X 1
